High-efficiency outboard with integrated 915 Wh high-performance lithium battery
Including onboard computer with GPS-based range calculation and charger
Ultra-quiet (33db), clean and compact
Silent direct-drive
Solar-chargeable
Instantaneous throttle response
Improved durability
3 HP equivalent
Completely waterproof (IP67)
Total weight: 17.3 kg (S) / 17.7 kg (L)
Shaft length: short 62.5 cm / long 75 cm

Travel 1103 C
The 1103 C model is the top-of-the-line model of our globally successful Travel series. Featuring a direct-drive motor design, it comes with the high-capacity 915 Wh battery – a range-extending 73% increase in capacity compared to the base model. The 1103 C delivers 1,100 W, a strong aluminium pylon for increased protection from impact damage and an upgraded transom mount.

Travel 1103 – Benefits:

With its integrated lithium battery and its outstanding efficiency, the Travel is the alternative to a small petrol outboard
Can do everything that a 3 HP petrol outboard can, plus it’s environmentally friendlier, quieter, lighter and more convenient
Completely waterproof (IP67)
Instantaneous throttle response
On-board computer with GPS-based calculation of remaining range
Solar rechargeable – including during the voyage
Can be easily dismantled for transport and space-saving storage; the outboard on its own weighs only 11.3 kg (S) / 11.7 kg (L)
A clean affair: no matter how or where you store your Travel – there’s no risk of leakage or petrol smells

Speed in knots (km/h)*    Range in sm (km)*    Running time in hours:
Slow    2.0 (3.7)    40.0 (74.0)    20:00
Half throttle    3.0 (5.5)    18.0 (33.0)    06:00
Full throttle    5.5 (10.0)    4.6 (8.3)    00:50

Technical Data Travel Travel 1103 C

Input power in watts    1100
Propulsive power in watts    520
Comparable petrol outboards (propulsive power)    3 HP
Comparable petrol outboards (thrust)    4 HP
Maximum overall efficiency in %    49
Static thrust in lbs*    70
Integrated battery    915 Wh Li-Ion
Nominal voltage    29.6
Final charging voltage    33.6
Total weight in kg    17.3 (S) / 17.7 (L)
Motor weight without battery in kg    11.3 (S) / 11.7 (L)
Weight of integrated battery    6.0
Shaft length in cm    62.5 (S) / 75 (L)
Standard propeller
v = speed in km/h at p = power in watts    v10/p1100
Alternative propeller options    v10/p1100 weedless
Propeller Guide
Maximum propeller speed in rpm    1,450
Control    Tiller
TorqLink    No
Steering    /-60° lockable
Tilting device    Manual, with impact protection, 78°
Trim device    Manual, 4-step
Integrated on-board computer    Yes
Stepless forward/reverse drive    Yes

Technical information:

Power Supply    EDAC EA11012E-240
Input Voltage    100 - 240 VAC
Input Frequency    50 - 60 Hz
Output Voltage    24 VDC
Output Current    4.16 A
Output Power    100 W
Average operational efficiency    ≥ 89 % at 25 %, 50 %, 75 %, 100 % output power
Efficiency at light loads (10 %)    ≥ 79 %
No Load Power consumption    ≤ 0.15 Wat at 0 % output power
